Features

• Designed to be compatible with new and old international standards, the charging voltage can be automatically configured according to the needs of different models to meet the charging needs of different models.

• Integrating Ethernet and 4G communication methods, the cloud service system has functions such as user charging, user settlement, reporting system, equipment maintenance, remote monitoring and management, etc. Managers can easily collect statistics on the operation of charging stations.

• Through the APP, you can perform functions such as positioning, navigation, booking charging, scanning QR Code charging, real-time inquiry, etc., and supports multiple payment methods.

• It has the function of intelligent power allocation. Multiple extensions can be charged at the same time. The charging machine will intelligently allocate the charging power according to the current requested by the charging vehicle.

• The complete electrical safety design has functions such as timing and real-time monitoring of safety protection, early diagnosis of equipment abnormalities, alarm feedback, and BMS independent safety protection.

• IP55 protection level, moisture-proof, mildew-proof, waterproof, dust-proof and flame-retardant. It has protection functions such as overheating, overload, short circuit, leakage, and anti-reverse battery connection.

• The user-friendly design makes it convenient for customers to swipe cards, take out guns to charge, and stop in emergencies. The charging gun head is equipped with an electronic lock to prevent the gun head from being pulled out at will during charging to ensure personal safety.

Dimensions

Applications
